Description
Part Number: 170254 (also associated with model EBS085.12)
Product Description
Reliable Braking Connection: Erich Jaeger 7-Pin 12V EBS/ABS Crimp-Type Trailer Socket
Ensure critical communication between your towing vehicle and trailer’s electronic braking system with the high-quality Erich Jaeger EBS085.12 7-Pin, 12V EBS/ABS Socket.
Designed to the international ISO 7638-1 standard, this socket is required for modern commercial vehicles to transmit essential data beyond basic ABS functions, optimising braking performance and safety.
This specific model uses robust crimp-type connections, ensuring a professional, durable, and vibration-proof installation when used with a specialised crimping tool.
The reinforced composite housing provides high mechanical resistance and water tightness, while a steel latching system prevents accidental disconnection.
This component is essential for safe and reliable 12V EBS systems.
Specifications:
Function: Electrical connection for ABS/EBS braking systems (Vehicle side socket)
Voltage: 12 Volts DC
Number of Pins: 7-Pin (compatible with both 5-pin ABS and 7-pin EBS systems)
Connection Type: Crimp contacts
Standards: Conforms to ISO 7638-1 standards
Compliance: Conforms to ADR/GGVS norm requirements
Housing Material: Reinforced composite plastic
Cable Suitability: For cable diameters between 9mm and 16mm
IP Rating: IP54 rated when mated with a compatible plug
Special Features: Bayonet lock, steel latch to prevent disconnection.
